Sta-Kon B71
Thomas & Betts Sta-Kon® B71 B Series Non-Insulated Ring Terminal, 18 to 14 AWG Conductor, 0.93 in L, Brazed Seam/Serrated Barrel, Copper, Metallic
Sta-Kon B71
Thomas & Betts Sta-Kon® B71 B Series Non-Insulated Ring Terminal, 18 to 14 AWG Conductor, 0.93 in L, Brazed Seam/Serrated Barrel, Copper, MetallicNon-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #B71
Werner Part #406776
UPC786210809243
Non-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #B71
Werner Part #406776
UPC786210809243
Product Description
Sta-Kon® Ring Terminal, Non-Insulated, Series: B Series, 18 to 14 AWG Conductor, 1/4 in Stud, 0.93 in Length, Brazed Seam/Serrated Barrel, Ring Tongue, 0.5 in W x 0.03 in THK Tongue, 600 VAC, 0.38 in Clearance, 150 deg C, Copper, Tin Coated, Metallic
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam/Serrated
ColorMetallic
Conductor size18 to 14 AWG
FinishTin Coated
ManufacturerThomas & Betts
MaterialCopper
SeriesB Series
Temperature Rating150 deg C
Tongue Size0.5 in W x 0.03 in THK
Tongue TypeRing
TypeNon-Insulated
Type / StyleNon-Insulated
Voltage Rating600 VAC
Country of OriginUnited States
Documents
Features
Non-insulated ring terminals are made of electrolytic copper for high conductivity/corrosion resistanceCan be installed with crimping tools having a single indenter or double indenter (recommended for solid wire)Serrated barrel to increases grip-on wire, brazed seam barrel provides maximum tensile strength1000 pieces/pack
Specifications
0.38 in Clearance
