Sta-Kon B14-250T
Thomas & Betts Sta-Kon® B14-250T 250 Non-Insulated Male Tab, 20 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, Metallic
Sta-Kon B14-250T
Thomas & Betts Sta-Kon® B14-250T 250 Non-Insulated Male Tab, 20 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, MetallicNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Sta-Kon® Male Tab, Non-Insulated, Series: 250, 20 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Crimp Terminal, 600 VAC, 0.03 in THK Stock, 150 deg C, Brass/Copper, Metallic, Tin Electro-Plated, 0.87 in L
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam
ColorMetallic
Conductor size20 to 14 AWG
Dimensions0.87 in L
FinishElectro Plated Tin
ManufacturerThomas & Betts
MaterialBrass
SeriesB 250
Tab Size0.25 in W x 0.032 in THK
Temperature Rating150 deg C
Terminal TypeCrimp
TypeNon-Insulated
Type / StyleNon-Insulated
Voltage Rating600 VAC
Country of OriginUnited States
Documents
Features
Brazed seam serrated barrel provides maximum tensile strength
Specifications
0.03 in Stock
