Sta-Kon 2RBS14X
Thomas & Betts Sta-Kon® 2RBS14X Heat Shrinkable Insulated Butt Splice Connector, 16 to 14 AWG Conductor, 1-1/2 in L, Copper, Blue
Sta-Kon 2RBS14X
Thomas & Betts Sta-Kon® 2RBS14X Heat Shrinkable Insulated Butt Splice Connector, 16 to 14 AWG Conductor, 1-1/2 in L, Copper, BlueNon-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #2RBS14X
Werner Part #63792
UPC786210703275
Non-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #2RBS14X
Werner Part #63792
UPC786210703275
Product Description
Sta-Kon® Butt Splice Connector, Heat Shrinkable Insulated, Series: RB Series, 16 to 14 AWG Conductor, 1-1/2 in Length, 600 VAC, Specifications: 0.2 in Maximum Insulation, 150 deg C, Copper, Blue, Electro-TiN Plated, 0.26 in W Dimensions
Attributes
Documents
Features
Specifications
Attributes
ColorBlue
Conductor size16 to 14 AWG
Dimensions0.26 in W
FinishElectro-TiN Plated
ManufacturerThomas & Betts
MaterialCopper
SeriesRB Series
Temperature Rating150 deg C
TypeHeat Shrinkable Insulated
Type / StyleHeat Shrinkable Insulated
Voltage Rating600 VAC
Country of OriginUnited States
Documents
Features
Heat shrinkable with electro tin platedSelf-insulated with heat shrinkable polyolefin and internally coated sealantCompleted installation, a fully sealed connection is achieved to protect the joint against the degrading effects of galvanic action, corrosion and environmental exposure
Specifications
0.2 in Maximum Insulation
