Sta-Kon 14RBD-187
Thomas & Betts Sta-Kon® 14RBD-187 187 Insulated Male Tab, 16 to 14 AWG Conductor, 0.187 in W x 0.032 in THK Tab, Brass/Copper, Blue
Sta-Kon 14RBD-187
Thomas & Betts Sta-Kon® 14RBD-187 187 Insulated Male Tab, 16 to 14 AWG Conductor, 0.187 in W x 0.032 in THK Tab, Brass/Copper, BlueNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Sta-Kon® Male Tab, Insulated, Series: 187, 16 to 14 AWG Conductor, 0.187 in W x 0.032 in THK Tab, Crimp Terminal, 600 VAC, 0.03 in THK Stock, 0.17 in Dia Maximum Vinyl Insulation, 105 deg C, Brass/Copper, Blue, Tin Plated, 0.87 in L
Attributes
Documents
Specifications
Attributes
ColorBlue
Conductor size16 to 14 AWG
Country of OriginUnited States
Dimensions0.87 in L
FinishTin Plated
ManufacturerThomas & Betts
MaterialBrass
Series187
Tab Size0.187 in W x 0.032 in THK
Temperature Rating105 deg C
Terminal TypeCrimp
TypeInsulated
Type / StyleInsulated
Voltage Rating600 VAC
Specifications
0.17 in Max Insulation, 0.03 in Stock THK
