Sta-Kon 14RB-250FCP
Thomas & Betts Sta-Kon® 14RB-250FCP Female Disconnect, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass, Blue, Insulated
Sta-Kon 14RB-250FCP
Thomas & Betts Sta-Kon® 14RB-250FCP Female Disconnect, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass, Blue, InsulatedNon-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #14RB-250FCP
Werner Part #3824598
UPC786210899398
Non-stock product. Available to order - lead time may vary.
BrandSta-Kon
MFG #14RB-250FCP
Werner Part #3824598
UPC786210899398
Product Description
Sta-Kon® Female Disconnect, Series: 250, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Crimp Terminal, 600 VAC, 0.17 in Dia Maximum Insulation, 0.03 in THK Stock, 105 deg C, Brass, Blue, Electroplated Tin, 0.96 in L x 0.29 in W, Insulated: Insulated
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam
ColorBlue
Conductor size16 to 14 AWG
Dimensions0.96 in L x 0.29 in W
FinishElectroplated Tin
InsulatedInsulated
ManufacturerThomas & Betts
MaterialBrass
Series250
Tab Size0.25 in W x 0.032 in THK
Temperature Rating105 deg C
Terminal TypeCrimp
Type / StyleDisconnects
Voltage Rating600 VAC
Country of OriginUnited States
Documents
Features
Vinyl insulatedUnique construction of the female disconnect offers long term dependabilityFunnel entry insulators enable easier inserting of wire into barrelBrazed seam serrated barrel provides maximum tensile strengthSuitable for use with WT145C, WT2000, WT112M, ERG4001, ERG4003 toolsColor-coded for easy installation
Specifications
0.17 in Dia Maximum Insulation, 0.03 in THK Stock
