Leviton WBR15-W
LevitonĀ® WBR15-W 1-Phase Duplex Heavy Duty Self-Grounding Weather Resistant Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White
Leviton WBR15-W
LevitonĀ® WBR15-W 1-Phase Duplex Heavy Duty Self-Grounding Weather Resistant Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, WhiteProduct Description
LevitonĀ® Straight Blade Receptacle, 1-Phase Duplex Heavy Duty Self-Grounding Weather Resistant, 125 VAC, 15 A, 1/2 hp, 2 Poles, 3 Wires, NEMA 5-15R, Commercial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Thermoplastic, White, 46 in H x 1.53 in W x 1.11 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating15
ColorWhite
Country of OriginMX
Dimensions46 in H x 1.53 in W x 1.11 in D
GradeCommercial
Horsepower1/2 hp
ManufacturerLeviton
MaterialThermoplastic
NEMA RatingNEMA 5-15R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
Type1-Phase Duplex Heavy Duty Self-Grounding Weather Resistant
Type / Style1-Phase Duplex Heavy Duty Self-Grounding Weather Resistant
Voltage Rating125 VAC
Documents
Features
Manufactured to withstand the demands of commercial and institutional applicationsHeavy duty brass power contacts for maximum conductivity and plug retentionShallow design for maximum wiring room in box
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL Federal Specification W-C-596 File No. E13399|UL 498 File No. E13399|UL94 V-2 Flammability Rating
