Leviton 460C7W
LevitonĀ® 460C7W Series II North American Configuration Watertight Pin and Sleeve Connector, 480 VAC, 60 A, 3 Poles, 4 Wires, Red
Leviton 460C7W
LevitonĀ® 460C7W Series II North American Configuration Watertight Pin and Sleeve Connector, 480 VAC, 60 A, 3 Poles, 4 Wires, RedNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
LevitonĀ® Pin and Sleeve Connector, North American Configuration Watertight, Series: Series II, 480 VAC, 60 A, 50/60 Hz, 3 Poles, 4 Wires, Industrial Grade, IP67 Enclosure, -40 to 60 deg C, Screw Terminal, ValoxĀ® 357, Red, 4.41 in Dia x 11.26 in L
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating60
ColorRed
Dimensions4.41 in Dia x 11.26 in L
Enclosure TypeIP67
Frequency Rating50/60 Hz
GradeIndustrial
ManufacturerLeviton
MaterialValoxĀ® 357
Number of Poles3
Number of Wires4
SeriesSeries II
Temperature Rating-40 to 60 deg C
Terminal TypeScrew
TypeNorth American Configuration Watertight
Type / StyleNorth American Configuration Watertight
Voltage Rating480 VAC
Country of OriginCzechia
Documents
Features
Rugged housing, made of superior performance PBT, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extremes and V-0 flame rated and superior UV stabilityWatertight chloroprene onion skin grommet provides a precise, reliable seal at the cable entry pointRear terminals, raised lettering identificationCalibrated, self-adjusting contactsFront terminals, raised lettering identification
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|CE 73/23/93/68/EEC|CSA C22.2 No. 182.1|IEC 60309-1/60309-2|UL 1682/1686|UL94 V-2 Flammability Rating
