Leviton 29W47
Leviton® Wetguard® 29W47 1-Phase Grounding Watertight Cable Mount Locking Connector, 125 VAC, 30 A, 2 Poles, 3 Wires, Yellow
Leviton 29W47
Leviton® Wetguard® 29W47 1-Phase Grounding Watertight Cable Mount Locking Connector, 125 VAC, 30 A, 2 Poles, 3 Wires, YellowNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Leviton® Wetguard® Locking Connector, 1-Phase Grounding Watertight Cable Mount, 125 VAC, 30 A, 2 Poles, 3 Wires, NEMA L5-30R, Industrial Grade, 5/8 to 1-1/8 in Cord Dia, -40 to 60 deg C, Screw Terminal, TPV, Yellow, 2.75 in Dia x 5.52 in L
Attributes
Documents
Specifications
Attributes
Amperage Rating30
ColorYellow
Dimensions2.75 in Dia x 5.52 in L
GradeIndustrial
ManufacturerLeviton
MaterialTPV
NEMA RatingNEMA L5-30R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeScrew
Type1-Phase Grounding Watertight Cable Mount
Type / Style1-Phase Grounding Watertight Cable Mount
Voltage Rating125 VAC
Country of OriginUnited States
Documents
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498|UL94 V-2 Flammability Rating
