Leviton 2410
Leviton® V-0-Max™ 2410 Grounding Locking Receptacle, 125/250 VAC, 20 A, 3 Poles, 4 Wires, Black
Leviton 2410
Leviton® V-0-Max™ 2410 Grounding Locking Receptacle, 125/250 VAC, 20 A, 3 Poles, 4 Wires, BlackOut of Stockmore info
|
BrandLeviton
MFG #2410
Werner Part #45040
UPC078477809327
Out of Stockmore info
|
BrandLeviton
MFG #2410
Werner Part #45040
UPC078477809327
Product Description
Leviton® V-0-Max™ Locking Receptacle, Grounding, 125/250 VAC, 20 A, 2 hp, 3 Poles, 4 Wires, NEMA L14-20R, Industrial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Polybutylene Terephthalate, Black, 3.63 in H x 1.69 in W x 1.31 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorBlack
Dimensions3.63 in H x 1.69 in W x 1.31 in D
GradeIndustrial
Horsepower2 hp
ManufacturerLeviton
MaterialPolybutylene Terephthalate
NEMA RatingNEMA L14-20R
Number of Poles3
Number of Wires4
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
TypeGrounding
Type / StyleGrounding
Voltage Rating125/250 VAC
Country of OriginMexico
Documents
Features
Box mounting14 to 8 AWG terminal accommodationFlush mount
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42|Federal Specification WC596/E13399|UL 498|UL94 V-0/V-2 Flammability Rating
