Leviton 2370
Leviton® V-0-Max™ 2370 3-Phase Y Non-Grounding Locking Receptacle, 250 VAC, 20 A, 3 Poles, 3 Wires, Black
Leviton 2370
Leviton® V-0-Max™ 2370 3-Phase Y Non-Grounding Locking Receptacle, 250 VAC, 20 A, 3 Poles, 3 Wires, BlackOut of StockMore Info
|
BrandLeviton
MFG #2370
Werner Part #45034
UPC078477045305
Out of StockMore Info
|
BrandLeviton
MFG #2370
Werner Part #45034
UPC078477045305
Product Description
Leviton® V-0-Max™ Locking Receptacle, 3-Phase Y Non-Grounding, 250 VAC, 20 A, 2 hp, 3 Poles, 3 Wires, NEMA L11-20R, Industrial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Polybutylene Terephthalate, Black, 3.63 in H x 1.69 in W x 1.31 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorBlack
Country of OriginMX
Dimensions3.63 in H x 1.69 in W x 1.31 in D
GradeIndustrial
Horsepower2 hp
ManufacturerLeviton
MaterialPolybutylene Terephthalate
NEMA RatingNEMA L11-20R
Number of Poles3
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
Type3-Phase Y Non-Grounding
Type / Style3-Phase Y Non-Grounding
Voltage Rating250 VAC
Documents
Features
Box mounting14 to 8 AWG terminal accommodationFlush mount
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD6/WD1/WD5|ANSI C73|NOM 057|CSA C22.2 No. 42|Federal Specification WC596|UL 498|UL94 V-0 Flammability Rating
