Leviton 2316
Leviton® V-0-Max™ 2316 Grounding Locking Flanged Outlet, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Leviton 2316
Leviton® V-0-Max™ 2316 Grounding Locking Flanged Outlet, 125 VAC, 20 A, 2 Poles, 3 Wires, WhiteNon-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #2316
Werner Part #45018
UPC078477801000
Non-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #2316
Werner Part #45018
UPC078477801000
Product Description
Leviton® V-0-Max™ Locking Flanged Outlet, Grounding, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA L6-20R, Industrial Grade, -40 to 60 deg C, Back Wired Terminal, Nylon, White, 2.5 in Dia x 1.78 in H
Attributes
Documents
Specifications
Attributes
Amperage Rating20
ColorWhite
Dimensions2.5 in Dia x 1.78 in H
GradeIndustrial
Horsepower1 HP
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA L6-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack Wire
TypeGrounding
Type / StyleGrounding
Voltage Rating125 VAC
Country of OriginUnited States
Documents
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498 File No. E13393|UL94 V-2 Flammability Rating
