Leviton 2310-B
Leviton® V-0-Max™ 2310-B Grounding Locking Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
Leviton 2310-B
Leviton® V-0-Max™ 2310-B Grounding Locking Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, BlackOut of StockMore Info
|
Out of StockMore Info
|
Product Description
Leviton® V-0-Max™ Locking Receptacle, Grounding, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA L5-20R, Industrial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Polybutylene Terephthalate, Black, 3.63 in H x 1.69 in W x 1.31 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorBlack
Country of OriginMX
Dimensions3.63 in H x 1.69 in W x 1.31 in D
GradeIndustrial
Horsepower1 hp
ManufacturerLeviton
MaterialPolybutylene Terephthalate
NEMA RatingNEMA L5-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
TypeGrounding
Type / StyleGrounding
Voltage Rating125 VAC
Documents
Features
Full rated current limitingRatings and NEMA ID permanently marked on device for identificationBox mounting14 to 8 AWG terminal accommodationFlush mount
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42/LR406|Federal Specification WC596/E13399|UL 498 File No. E13399|UL94 V-0/V-2 Flammability Rating
