Leviton 1201-PLG
LevitonĀ® 1201-PLG Illuminated ON Self-Grounding AC Quiet Toggle Switch, 120 VAC, 15 A, 1/2 hp Power Rating, SP Contact
Leviton 1201-PLG
LevitonĀ® 1201-PLG Illuminated ON Self-Grounding AC Quiet Toggle Switch, 120 VAC, 15 A, 1/2 hp Power Rating, SP ContactOut of StockMore Info
|
BrandLeviton
MFG #1201-PLG
Werner Part #3976611
UPC078477224403
Out of StockMore Info
|
BrandLeviton
MFG #1201-PLG
Werner Part #3976611
UPC078477224403
Product Description
LevitonĀ® AC Quiet Toggle Switch, Illuminated ON Self-Grounding, 120 VAC, 15 A, 1/2 hp Power, SP Contact Configuration, 1 Pole, Toggle Actuator, NEMA WD-1/WD-6 Enclosure, Surface Mounting, Back/Side Wired Terminal, 50000 Cycles Operating Cycles, Thermoplastic, Green, Environmental Conditions: -40 to 65 deg C Operating Temperature, 46 in H x 1.31 in W x 1.6 in D Dimensions
Attributes
Documents
Features
Specifications
Attributes
Actuator TypeToggle
Amperage Rating15
ColorGreen
Country of OriginMX
Dimensions46 in H x 1.31 in W x 1.6 in D
Electrical Ratings1/2 hp
Enclosure TypeNEMA WD-1/WD-6
ManufacturerLeviton
MaterialThermoplastic
Mounting TypeSurface
Number of Poles1
Temperature Rating-40 to 65 deg C Operating Temperature
Terminal TypeBack/Side Wire
TypeIlluminated ON Self-Grounding
Type / StyleIlluminated ON Self-Grounding
Voltage Rating120 VAC
Documents
Features
Pilot light and lighted handle switches provide top performance in punishing industrial applicationsLighted handle illuminated when load is OFFPilot light toggle illuminated when load is ONFully enclosed switch mechanism in rugged housing for strength, tracking and arc resistanceSelf-grounding clip (self grounding when used with a grounded metal wallbox)1/2 hp at 120 VAC power rating
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No. 111 File No. 152105|NOM 057|Federal Specification WS896E File No. E7458|UL 20|UL94 V-2 Flammability Rating
