Decora T5825-E
Leviton® Decora® T5825-E Duplex Self-Grounding Tamper-Resistant Ultrasonically Welded Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
Decora T5825-E
Leviton® Decora® T5825-E Duplex Self-Grounding Tamper-Resistant Ultrasonically Welded Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, BlackOut of StockMore Info
|
BrandDecora
MFG #T5825-E
Werner Part #4016972
UPC078477450512
Out of StockMore Info
|
BrandDecora
MFG #T5825-E
Werner Part #4016972
UPC078477450512
Product Description
Leviton® Decora® Straight Blade Receptacle, Duplex Self-Grounding Tamper-Resistant Ultrasonically Welded, 125 VAC, 20 A, 2 Pole, 3 Wires, NEMA 5-20R, Grade: Commercial, -40 to 60 deg C, Quickwire/Push-In/Side Wired Terminal, Thermoplastic, Black, 4.2 in H x 1.351 in W x 1.184 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorBlack
Country of OriginCN
Dimensions4.2 in H x 1.351 in W x 1.184 in D
GradeCommercial
ManufacturerLeviton
MaterialThermoplastic
NEMA RatingNEMA 5-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeQuick-Wire® Push-In/Side Wire
TypeDuplex Self-Grounding Tamper-Resistant Ultrasonically Welded
Type / StyleDuplex Self-Grounding Tamper-Resistant Ultrasonically Welded
Voltage Rating125 VAC
Documents
Features
Terminal screws accept up to #12 AWG copper or copper clad wireDouble wipe power contacts for reliable conductivity and plug retentionHeavy gauge zinc plated steel mounting strap
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed|CSA File No. 152105|NOM Certified|UL94 V-2 Flammability Rating
Leviton® Decora® T5825-E Duplex Self-Grounding Tamper-Resistant Ultrasonically Welded Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
