Color-Keyed MD250M-4
Thomas & Betts Color-Keyed® Kube™ MD250M-4 1-Load Male Motor Lead Pigtail Disconnect, 250 kcmil Beryllium Copper Conductor, Die Code: 62, 0.81 in Stud, Copper
Color-Keyed MD250M-4
Thomas & Betts Color-Keyed® Kube™ MD250M-4 1-Load Male Motor Lead Pigtail Disconnect, 250 kcmil Beryllium Copper Conductor, Die Code: 62, 0.81 in Stud, CopperOut of Stockmore info
|
BrandColor-Keyed
MFG #MD250M-4
Werner Part #3871183
UPC786209893185
Out of Stockmore info
|
BrandColor-Keyed
MFG #MD250M-4
Werner Part #3871183
UPC786209893185
Product Description
Color-Keyed® Kube™ Motor Lead Pigtail Disconnect, 1-Load Male, Beryllium Copper Conductor, 250 kcmil Conductor, Die Code: 62, 600 VAC, 0.81 in Stud, Boot MDBOOT4 Insulation, Body Size 4, Tin Plated Finish, Copper, Yellow, 2.89 in L x 2.69 in W
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size250 kcmil
Conductor TypeBeryllium Copper
Country of OriginMX
Die Code62
Insulation TypeBoot MDBOOT4
ManufacturerThomas & Betts
Stud Size0.81 in
Type / Style1-Load Male
Voltage600 VAC
Documents
Applications
For 600 VAC and 5 kVAC applications
Features
One line to one load (2-wire)Fast, snap together assembly offers maximum labor savingsNot need for nuts, bolts and washers or insulating tape - simply slide on reusable bootQuick disconnect, no knife cutting of melted tape, eliminating the risk of accidental cutting of wire insulation, resulting motor downtime and installer exposureMeet or exceed electrical and mechanical performance of bolted connectionsConstructed of high conductivity copper with tin plated finishThermoplastic elastomer insulatorQuick, reliable change out of electric motors with no bolting, taping or loose connectionsTotal assembly fits into tight motor housings
Specifications
Body Size 4, Tin Plated Finish
