Color-Keyed MD1M-3
Thomas & Betts Color-Keyed® Kube™ MD1M-3 1-Load Male Motor Lead Pigtail Disconnect, 1 AWG Beryllium Copper Conductor, Die Code: 37, 1/2 in Stud, Copper
Color-Keyed MD1M-3
Thomas & Betts Color-Keyed® Kube™ MD1M-3 1-Load Male Motor Lead Pigtail Disconnect, 1 AWG Beryllium Copper Conductor, Die Code: 37, 1/2 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Kube™ Motor Lead Pigtail Disconnect, 1-Load Male, Beryllium Copper Conductor, 1 AWG Conductor, Die Code: 37, 600 VAC, 1/2 in Stud, Boot MDBOOT3 Insulation, 9/16 in Strip Length, Body Size 3, Tin Plated Finish, Copper, Green Color Code, 1.56 in L x 1.75 in W
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size1 AWG
Conductor TypeBeryllium Copper
Country of OriginMX
Die Code37
Insulation TypeBoot MDBOOT3
ManufacturerThomas & Betts
Stud Size1/2 in
Type / Style1-Load Male
Voltage600 VAC
Documents
Applications
For 600 VAC and 5 kVAC applications
Features
One line to one load (2-wire)Fast, snap together assembly offers maximum labor savingsNot need for nuts, bolts and washers or insulating tape - simply slide on reusable bootQuick disconnect, no knife cutting of melted tape, eliminating the risk of accidental cutting of wire insulation, resulting motor downtime and installer exposureMeet or exceed electrical and mechanical performance of bolted connectionsConstructed of high conductivity copper with tin plated finishThermoplastic elastomer insulatorQuick, reliable change out of electric motors with no bolting, taping or loose connectionsTotal assembly fits into tight motor housings
Specifications
Body Size 3, Tin Plated Finish
