Color-Keyed M2D8M-1
Thomas & Betts Color-Keyed® Kube™ M2D8M-1 2-Load Male Motor Lead Pigtail Disconnect, 8 AWG Beryllium Copper Conductor, Die Code: 21, 1/4 in Stud, Copper
Color-Keyed M2D8M-1
Thomas & Betts Color-Keyed® Kube™ M2D8M-1 2-Load Male Motor Lead Pigtail Disconnect, 8 AWG Beryllium Copper Conductor, Die Code: 21, 1/4 in Stud, CopperOut of Stockmore info
|
BrandColor-Keyed
MFG #M2D8M-1
Werner Part #64857
UPC786210832043
Out of Stockmore info
|
BrandColor-Keyed
MFG #M2D8M-1
Werner Part #64857
UPC786210832043
Product Description
Color-Keyed® Kube™ Motor Lead Pigtail Disconnect, 2-Load Male, Beryllium Copper Conductor, 8 AWG Conductor, Die Code: 21, 600 VAC, 1/4 in Stud, Boot M2DBOOT1 Insulation, 7/16 in Strip Length, Body Size 1, Tin Plated Finish, Copper, Red, 0.82 in L x 1.13 in W
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size8 AWG
Conductor TypeBeryllium Copper
Country of OriginMX
Die Code21
Insulation TypeBoot M2DBOOT1
ManufacturerThomas & Betts
Stud Size1/4 in
Type / Style2-Load Male
Voltage600 VAC
Documents
Applications
For 600 VAC and 5 kVAC applications
Features
One line to two load (3-wire)Fast, snap together assembly offers maximum labor savingsNot need for nuts, bolts and washers or insulating tape - simply slide on reusable bootQuick disconnect, no knife cutting of melted tape, eliminating the risk of accidental cutting of wire insulation, resulting motor downtime and installer exposureMeet or exceed electrical and mechanical performance of bolted connectionsConstructed of high conductivity copper with tin plated finishColor coded to match installing diesQuick, reliable change out of electric motors with no bolting, taping or loose connectionsTotal assembly fits into tight motor housings1000 VAC maximum in signs and fixturesKON-TOUR louvered contact bandsComplete line of motor lead disconnects for 600 VAC and 5 kV applications, covering wire range from 16 to 4/0 AWG
Specifications
Body Size 1, Tin Plated Finish
