Color-Keyed BAC20SPBT
Thomas & Betts Color-Keyed® BAC20SPBT 1-Stage Heavy Duty Battery Connector,) 2/0 AWG Conductor, Straight Termination, Copper Housing
Color-Keyed BAC20SPBT
Thomas & Betts Color-Keyed® BAC20SPBT 1-Stage Heavy Duty Battery Connector,) 2/0 AWG Conductor, Straight Termination, Copper HousingOut of Stockmore info
|
BrandColor-Keyed
MFG #BAC20SPBT
Werner Part #3797816
UPC786210972886
Out of Stockmore info
|
BrandColor-Keyed
MFG #BAC20SPBT
Werner Part #3797816
UPC786210972886
Product Description
Color-Keyed® Battery Connector, 1-Stage Heavy Duty, 2/0 AWG Conductor, Straight Termination, Copper Housing, SAE Conductor, Orange, Tin Electroplated, 0.502 in ID x 0.676 in OD x 2.21 in L
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size2/0 AWG
Country of OriginUS
ManufacturerThomas & Betts
Type / Style1-Stage Heavy Duty
Documents
Applications
For positive post
Features
TBM5-SV, TBM5V, TBM8250, TBM8250S installing toolsEach color coded cable size is color matched to the proper connector and installing tool dies have the right connector, cable and die combinationUnique cable stripper easily removes the cable insulation without damaging the cable strands and our compression tool and closed barrel connector assure a solid homogeneous mass that provides an optimum electrical bond between connector and cableCut and strip cable with proper T&B® tools
Specifications
SAE Conductor
