Color-Keyed 60554
Thomas & Betts Color-Keyed® 60554 2-Way Standard Barrel Splice Connector, 250 kcmil Aluminum/Copper Conductor, Die Code: 71, 3.91 in L, Aluminum
Color-Keyed 60554
Thomas & Betts Color-Keyed® 60554 2-Way Standard Barrel Splice Connector, 250 kcmil Aluminum/Copper Conductor, Die Code: 71, 3.91 in L, AluminumOut of Stockmore info
|
BrandColor-Keyed
MFG #60554
Werner Part #64297
UPC786210605548
Out of Stockmore info
|
BrandColor-Keyed
MFG #60554
Werner Part #64297
UPC786210605548
Product Description
Color-Keyed® Splice Connector, 2-Way Standard Barrel, Aluminum/Copper Conductor, 250 kcmil Conductor, Die Code: 71, 35 kV, 0.92 in OD, 3.91 in Length, Specifications: TiN Plated Finish, 90 deg C, Aluminum, Red Color Code
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size250 kcmil
Conductor TypeAluminum/Copper
Country of OriginMX
Die Code71
Length3.91 in
ManufacturerThomas & Betts
Outside Diameter0.92 in
Type / Style2-Way Standard Barrel
Voltage35 kV
Documents
Applications
For aluminum to copper or aluminum to aluminum splicing
Features
Manufactured from high conductivity wrought aluminum and electro tin platedConnectors are pre-filled with oxide inhibitorPermits aluminum conductors to be spliced to copper or aluminum conductorsFor aluminum and copper concentric conductors and compact code aluminum strandsSuitable for use with TBM6, TBM6S, TBM8, TBM8S toolsConnectors supplied with T&B® oxide inhibitor compound in wire bore
Specifications
TiN Plated Finish
