Color-Keyed 60501-TB
Thomas & Betts Color-Keyed® 60501-TB 2-Way Compression Splice Connector, 8 AWG Stranded Conductor, Die Code: 24, 1-1/4 in L, Copper/Wrought Aluminum
Color-Keyed 60501-TB
Thomas & Betts Color-Keyed® 60501-TB 2-Way Compression Splice Connector, 8 AWG Stranded Conductor, Die Code: 24, 1-1/4 in L, Copper/Wrought AluminumInventory Not Available
Inventory Not Available
Product Description
Color-Keyed® Compression Splice Connector, 2-Way, Stranded Conductor, 8 AWG Conductor, Die Code: 24, 1-1/4 in Length, 35 kVA, 90 deg C, Copper/Wrought Aluminum, Electro-TiN Coated, Blue, 1.19 in L x 0.28 in W Dimensions
Attributes
Documents
Features
Specifications
Attributes
Conductor size8 AWG
Conductor TypeStranded
Country of OriginMX
Die Code24
Length1-1/4 in
ManufacturerThomas & Betts
Type / Style2-Way
Voltage35 kV
Documents
Features
Connectors are pre-filled with oxide inhibitorFor 90 deg C certified to 600 VAC and recommended up to 35 kVAC applicationsFor aluminum and copper concentric conductors and compact code aluminum strandsPermits aluminum conductors to be spliced to copper or aluminum conductorsHigh conductivity material
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL File No. E9809|CSA Certified
