Color-Keyed 54946BE
Thomas & Betts Color-Keyed® 54946BE 54900 1-Hole Compression Lug, 1/0 AWG Copper/Stranded Conductor, Die Code: 42, #10 Stud, Copper
Color-Keyed 54946BE
Thomas & Betts Color-Keyed® 54946BE 54900 1-Hole Compression Lug, 1/0 AWG Copper/Stranded Conductor, Die Code: 42, #10 Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Lug, 1-Hole, Series: 54900, Copper/Stranded Conductor, 1/0 AWG Conductor, Die Code: 42, 35 kV, #10 Stud, Straight Tongue, 0.65 in L x 0.75 in W x 0.13 in THK Tongue, 1.95 in Overall Length, Blind End/Long Barrel, 0.52 in Dia Barrel, 0.204 in Mounting Hole, Copper, Pink
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.52 in Dia
Barrel TypeBlind End/Long
Conductor size1/0 AWG
Conductor TypeCopper/Stranded
Country of OriginMX
Die Code42
Hole SizeMounting Hole Size: 0.204 in
ManufacturerThomas & Betts
Overall Length1.95 in
Stud Size#10
Tongue Size0.65 in L x 0.75 in W x 0.13 in THK
Tongue TypeStraight
Type / Style1-Hole
Voltage35 kV
Documents
Applications
For providing a high degree of reliability in electrical wiring
Features
Peep holeHigh conductivity wrought copper3/4 in hole spacing
Specifications
Standards/Approvals: ARRA Compliant|BAA Compliant|CSA C22.2 File No 65/04|RoHS Compliant|UL 467/486A/File No E9809
