Color-Keyed 54809
Thomas & Betts Color-Keyed® 54809 2-Way Long Barrel Splice Connector, 1/0 AWG Copper Conductor, Die Code: 42, 2 in L, Copper
Color-Keyed 54809
Thomas & Betts Color-Keyed® 54809 2-Way Long Barrel Splice Connector, 1/0 AWG Copper Conductor, Die Code: 42, 2 in L, CopperOut of Stockmore info
|
BrandColor-Keyed
MFG #54809
Werner Part #410258
UPC786210548098
Out of Stockmore info
|
BrandColor-Keyed
MFG #54809
Werner Part #410258
UPC786210548098
Product Description
Color-Keyed® Splice Connector, 2-Way Long Barrel, Copper Conductor, 1/0 AWG Conductor, Die Code: 42, 600 VAC, 0.54 in Outside Dia, 2 in Length, Tin Plated Finish, Copper, Pink Color Code
Attributes
Documents
Features
Specifications
Attributes
Conductor size1/0 AWG
Conductor TypeCopper
Country of OriginMX
Die Code42
Length2 in
ManufacturerThomas & Betts
Outside Diameter0.54 in
Type / Style2-Way Long Barrel
Voltage600 VAC
Documents
Features
2-way connector provides high pullout values, easy-to insulate and provide a low resistance connection of high quality and low installed costColor coded for correct matching of installing die and connector35 kV voltage rating225/24 = 90.8 kcmil wire size flex
Specifications
Tin Plated Finish
