Color-Keyed 54625-TB
Thomas & Betts Color-Keyed® 54625-TB Wire Joint, 600 VAC, 12 to 8 AWG Solid/Stranded, 2 AWG Stranded Wire, 0.479 in L, Copper
Color-Keyed 54625-TB
Thomas & Betts Color-Keyed® 54625-TB Wire Joint, 600 VAC, 12 to 8 AWG Solid/Stranded, 2 AWG Stranded Wire, 0.479 in L, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Wire Joint, 600 VAC, 12 to 8 AWG Solid/Stranded, 2 AWG Stranded Wire, 0.479 in Length, 90 deg C, For Use With: Copper Cable, Copper, Green, Tin Plated, 0.545 in W
Attributes
Documents
Applications
Features
Specifications
Attributes
Country of OriginMX
Length0.479 in
ManufacturerThomas & Betts
Voltage600 VAC
Documents
Applications
For pigtailing and tapping multiple conductors or 2-way splicing
Features
Offers lowest installed costForm a permanent installation in minimal space, easily insulatedColor coded to dies for positive matching and compressionAll-around compression ensures high conductivity, low resistance and high pull-out values exceeding CSA requirements66040 to 87130 circular mil area
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|CSA Certified|UL Listed
