Color-Keyed 54507
Thomas & Betts Color-Keyed® 54507 2-Way Standard Barrel Splice Connector, 2 AWG Copper Conductor, Die Code: 33, 1-1/4 in L, Copper
Color-Keyed 54507
Thomas & Betts Color-Keyed® 54507 2-Way Standard Barrel Splice Connector, 2 AWG Copper Conductor, Die Code: 33, 1-1/4 in L, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Splice Connector, 2-Way Standard Barrel, Copper Conductor, 2 AWG Conductor, Die Code: 33, 600 VAC, 0.41 in Outside Dia, 1-1/4 in Length, Tin Plated Finish, Copper, Brown Color Code
Attributes
Documents
Features
Specifications
Attributes
Conductor size2 AWG
Conductor TypeCopper
Country of OriginMX
Die Code33
Length1-1/4 in
ManufacturerThomas & Betts
Outside Diameter0.41 in
Type / Style2-Way Standard Barrel
Voltage600 VAC
Documents
Features
2-way connectors provide high pullout values, are easy to insulate and provide a low resistance connection of high quality and low installed costColor coded for correct matching of installing die and connector35 kV max voltage125/24 = 50.4 kcmil, NO 4 Weld wire size flex
Specifications
Tin Plated Finish
