Color-Keyed 54506
Thomas & Betts Color-Keyed® 54506 2-Way Standard Barrel Splice Connector, 4 AWG Copper Conductor, Die Code: 29, 1 in L, Copper
Color-Keyed 54506
Thomas & Betts Color-Keyed® 54506 2-Way Standard Barrel Splice Connector, 4 AWG Copper Conductor, Die Code: 29, 1 in L, CopperNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Color-Keyed® Splice Connector, 2-Way Standard Barrel, Copper Conductor, 4 AWG Conductor, Die Code: 29, 35 kV, 0.37 in OD, 1 in Length, Specifications: TiN Plated Finish, Copper, Gray Color Code
Attributes
Documents
Features
Specifications
Attributes
Conductor size4 AWG
Conductor TypeCopper
Die Code29
ManufacturerThomas & Betts
MaterialCopper
Type2-Way Standard Barrel
Type / Style2-Way Standard Barrel
Voltage Rating35 kV
Country of OriginMexico
Documents
Features
2-way connectors provide high pullout values, are easy to insulate and provide a low resistance connection of high quality and low installed costColor coded for correct matching of installing die and connector
Specifications
Tin Plated
