Color-Keyed 54481
Thomas & Betts Color-Keyed® 54481 54400 2-Hole High Voltage Compression Connector Lug, 300 kcmil Copper Conductor, Die Code: 66R, 1/2 in Stud, Copper
Color-Keyed 54481
Thomas & Betts Color-Keyed® 54481 54400 2-Hole High Voltage Compression Connector Lug, 300 kcmil Copper Conductor, Die Code: 66R, 1/2 in Stud, CopperOut of Stockmore info
|
BrandColor-Keyed
MFG #54481
Werner Part #3778097
UPC786210544816
Out of Stockmore info
|
BrandColor-Keyed
MFG #54481
Werner Part #3778097
UPC786210544816
Product Description
Color-Keyed® Compression Connector Lug, 2-Hole High Voltage, Series: 54400, Copper Conductor, 300 kcmil Conductor, Die Code: 66R, 15 kVAC, 1/2 in Stud, Straight Tongue, 5.011 in L x 1.19 in W x 0.16 in THK Tongue, 5.16 in Overall Length, Blind End/Long Barrel, 13/16 in Dia Barrel, 1-3/4 in Hole Spacing, Tin Plated Finish, 105 deg C, 0.531 in Mounting Hole, Copper, White
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size13/16 in Dia
Barrel TypeBlind End/Long
Conductor size300 kcmil
Conductor TypeCopper
Country of OriginMX
Die Code66R
Hole SizeMounting Hole Size: 0.531 in
ManufacturerThomas & Betts
Overall Length5.16 in
Stud Size1/2 in
Tongue Size5.011 in L x 1.19 in W x 0.16 in THK
Tongue TypeStraight
Type / Style2-Hole High Voltage
Voltage15 kVAC
Documents
Applications
For providing a high degree of reliability in electrical wiring
Features
Recommended for up to 15 kVAC applications, installed with standard t and b tools with special rounding diesThe rounding die overlapped compressions provide a smooth round surfaceThis combined with the tapered barrel ends, addresses the controlling of potentially damaging electrical stresses of high voltagesRound hole
Specifications
1-3/4 in Hole Spacing, Tin Plated Finish
