Color-Keyed 54409
Thomas & Betts Color-Keyed® 54409 54400 1-Hole High Voltage Compression Connector Lug, 1/0 AWG Copper Conductor, Die Code: 42R, 3/8 in Stud, Copper
Color-Keyed 54409
Thomas & Betts Color-Keyed® 54409 54400 1-Hole High Voltage Compression Connector Lug, 1/0 AWG Copper Conductor, Die Code: 42R, 3/8 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Connector Lug, 1-Hole High Voltage, Series: 54400, Copper Conductor, 1/0 AWG Conductor, Die Code: 42R, 15 kVAC, 3/8 in Stud, Straight Tongue, 3 in L x 0.75 in W x 0.12 in THK Tongue, 2.38 in Overall Length, Blind End/Long Barrel, 0.81 in Dia Barrel, Tin Plated Finish, 105 deg C, 0.406 in Mounting Hole, Copper, Pink
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.81 in Dia
Barrel TypeBlind End/Long
Conductor size1/0 AWG
Conductor TypeCopper
Country of OriginMX
Die Code42R
Hole SizeMounting Hole Size: 0.406 in
ManufacturerThomas & Betts
Overall Length2.38 in
Stud Size3/8 in
Tongue Size3 in L x 0.75 in W x 0.12 in THK
Tongue TypeStraight
Type / Style1-Hole High Voltage
Voltage15 kVAC
Documents
Applications
For providing a high degree of reliability in electrical wiring
Features
Round hole
Specifications
Tin Plated Finish
