Color-Keyed 54174UF
Thomas & Betts Color-Keyed® 54174UF 54100 1-Hole Compression Connector Lug With Peep Hole, 250 kcmil Copper Conductor, Die Code: 62, 3/8 in Stud, Copper
Color-Keyed 54174UF
Thomas & Betts Color-Keyed® 54174UF 54100 1-Hole Compression Connector Lug With Peep Hole, 250 kcmil Copper Conductor, Die Code: 62, 3/8 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Connector Lug, 1-Hole, Series: 54100, Copper Conductor, 250 kcmil Conductor, Die Code: 62, 35 kVAC, 3/8 in Stud, 45 deg Tongue, 0.93 in L x 1.13 in W x 0.14 in THK Tongue, Standard Barrel, 0.77 in Dia Barrel, Tin Plated Finish, Copper, Yellow
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.77 in Dia
Barrel TypeStandard
Conductor size250 kcmil
Conductor TypeCopper
Country of OriginMX
Die Code62
ManufacturerThomas & Betts
Stud Size3/8 in
Tongue Size0.93 in L x 1.13 in W x 0.14 in THK
Tongue Type45 deg
Type / Style1-Hole
Voltage35 kVAC
Documents
Features
High conductivity wrought copper construction
Specifications
Tin Plated Finish
