Color-Keyed 54111UB
Thomas & Betts Color-Keyed® 54111UB 54100 1-Hole Compression Lug, 3/0 AWG Copper Conductor, Die Code: 50, 3/8 in Stud, Copper
Color-Keyed 54111UB
Thomas & Betts Color-Keyed® 54111UB 54100 1-Hole Compression Lug, 3/0 AWG Copper Conductor, Die Code: 50, 3/8 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Lug, 1-Hole, Series: 54100, Copper Conductor, 3/0 AWG Conductor, Die Code: 50, 35 kVAC, 3/8 in Stud, 90 deg Tongue, 0.93 in L x 0.92 in W x 0.13 in THK Tongue, Standard Barrel, 0.63 in Dia Barrel, 0.406 in Mounting Hole, Copper, Orange
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.63 in Dia
Barrel TypeStandard
Conductor size3/0 AWG
Conductor TypeCopper
Country of OriginMX
Die Code50
Hole SizeMounting Hole Size: 0.406 in
ManufacturerThomas & Betts
Stud Size3/8 in
Tongue Size0.93 in L x 0.92 in W x 0.13 in THK
Tongue Type90 deg
Type / Style1-Hole
Voltage35 kVAC
Documents
Applications
For providing a high degree of reliability in electrical wiring
Features
Peep holeHigh conductivity wrought copper constructionTin plated finish
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL File No. E9809|CSA Certified
