Color-Keyed 256-30695-188
Thomas & Betts Color-Keyed® 256-30695-188 2-Hole Compression Connector Lug With Peep Hole, 500 kcmil Copper Conductor, Die Code: 87, 1/2 in Stud, Copper
Color-Keyed 256-30695-188
Thomas & Betts Color-Keyed® 256-30695-188 2-Hole Compression Connector Lug With Peep Hole, 500 kcmil Copper Conductor, Die Code: 87, 1/2 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Connector Lug, 2-Hole, Copper Conductor, 500 kcmil Conductor, Die Code: 87, 35 kVAC, 1/2 in Stud, 2.31 in L x 1.63 in W x 0.22 in THK Tongue, 4.06 in Overall Length, Standard Barrel, 1.1 in Dia Barrel, 1-1/4 in Hole Spacing, Tin Plated Finish, Copper, Brown
Attributes
Documents
Features
Specifications
Attributes
Barrel Size1.1 in Dia
Barrel TypeStandard
Conductor size500 kcmil
Conductor TypeCopper
Country of OriginMX
Die Code87
ManufacturerThomas & Betts
Overall Length4.06 in
Stud Size1/2 in
Tongue Size2.31 in L x 1.63 in W x 0.22 in THK
Type / Style2-Hole
Voltage35 kVAC
Documents
Features
High conductivity wrought copper construction
Specifications
1-1/4 in Hole Spacing, Tin Plated Finish
