Color-Keyed 256-30695-1370
Thomas & Betts Color-Keyed® 256-30695-1370 1-Hole Compression Connector Lug With Peep Hole, 600 kcmil Copper Conductor, Die Code: 94, 1/2 in Stud, Copper
Color-Keyed 256-30695-1370
Thomas & Betts Color-Keyed® 256-30695-1370 1-Hole Compression Connector Lug With Peep Hole, 600 kcmil Copper Conductor, Die Code: 94, 1/2 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Connector Lug, 1-Hole, Copper Conductor, 600 kcmil Conductor, Die Code: 94, 35 kVAC, 1/2 in Stud, 1.44 in L x 1.75 in W x 0.24 in THK Tongue, 3.65 in Overall Length, Standard Barrel, 1.2 in Dia Barrel, 13/16 in Hole Spacing, Tin Plated Finish, Copper, Green
Attributes
Documents
Features
Specifications
Attributes
Barrel Size1.2 in Dia
Barrel TypeStandard
Conductor size600 kcmil
Conductor TypeCopper
Country of OriginMX
Die Code94
ManufacturerThomas & Betts
Overall Length3.65 in
Stud Size1/2 in
Tongue Size1.44 in L x 1.75 in W x 0.24 in THK
Type / Style1-Hole
Voltage35 kVAC
Documents
Features
High conductivity wrought copper construction13/16 in hole to tongue end
Specifications
13/16 in Hole Spacing, Tin Plated Finish
