Color-Keyed 256-30695-1016
Thomas & Betts Color-Keyed® 256-30695-1016 2-Hole Compression Lug, 3 to 2 AWG Copper Conductor, Die Code: 33, 1/4 in Stud, Copper
Color-Keyed 256-30695-1016
Thomas & Betts Color-Keyed® 256-30695-1016 2-Hole Compression Lug, 3 to 2 AWG Copper Conductor, Die Code: 33, 1/4 in Stud, CopperOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Color-Keyed® Compression Lug, 2-Hole, Copper Conductor, 3 to 2 AWG Conductor, Die Code: 33, 35 kVAC, 1/4 in Stud, 1.88 in L x 0.67 in W x 0.09 in THK Tongue, 3.06 in Overall Length, Blind End/Long Barrel, 0.67 in Dia Barrel, 1 in Hole Spacing, Copper, Brown
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.67 in Dia
Barrel TypeBlind End/Long
Conductor size3 to 2 AWG
Conductor TypeCopper
Country of OriginMX
Die Code33
ManufacturerThomas & Betts
Overall Length3.06 in
Stud Size1/4 in
Tongue Size1.88 in L x 0.67 in W x 0.09 in THK
Type / Style2-Hole
Voltage35 kVAC
Documents
Features
Peep holeHigh conductivity wrought copper constructionTin plated finish
Specifications
1 in Hole Spacing
