Carlon NS10106
Thomas & Betts Carlon® Circuit Safe® NS10106 NEMA Enclosure With Opaque Cover, 10 in L x 6 in W x 10 in D, NEMA 1/2/3/3S/3X/3SX/4/4X/12 NEMA Rating, Polycarbonate
Carlon NS10106
Thomas & Betts Carlon® Circuit Safe® NS10106 NEMA Enclosure With Opaque Cover, 10 in L x 6 in W x 10 in D, NEMA 1/2/3/3S/3X/3SX/4/4X/12 NEMA Rating, PolycarbonateNon-stock product. Available to order - lead time may vary.
BrandCarlon
MFG #NS10106
Werner Part #640758
UPC034481007432
Non-stock product. Available to order - lead time may vary.
BrandCarlon
MFG #NS10106
Werner Part #640758
UPC034481007432
Product Description
Carlon® Circuit Safe® NEMA Enclosure, 10 in Length, 6 in Width, 10 in Depth, NEMA 1/2/3/3S/3X/3SX/4/4X/12, Screw-On Cover, 8.75 in H x 8.88 in W Panel, Latch Lock, Wall Mount, -30 to 230 deg F, Polycarbonate, Gray
Attributes
Documents
Features
Specifications
Attributes
ColorGray
Cover TypeScrew-On
MaterialPolycarbonate
Mounting TypeWall
NEMA RatingNEMA 1/2/3/3S/3X/3SX/4/4X/12
Panel Size8.75 in H x 8.88 in W
Size8.88 in W x 8.75 in H
Temperature Rating-30 to 230 deg F
Type / StyleCircuit Safe NEMA Enclosures
Country of OriginUnited States
ManufacturerThomas & Betts
Documents
Features
100% non-metallic construction, including hingesSturdy SS latches install without penetration of the enclosure baseAll cover screws are captivePanel suspension system allows the installation of panels at any depth, including stacking of multiple panelsNon-metallic mounting rails for easy installationLess than half the weight of metal enclosures, 25% lighter than fiberglass, easier to handle and less expensive to ship380 V/mil dielectric strength, 3 at 60 Hz, 2.96 at 106 Hz dielectric constant
Specifications
Latch
