Decora 5613-2I
Leviton® Decora® 5613-2I 3-Way Grounding Lighted Handle Illuminated AC Quiet Switch With Grounding Screw, 120/277 VAC, 15 A, 1/2 hp, 2 hp
Decora 5613-2I
Leviton® Decora® 5613-2I 3-Way Grounding Lighted Handle Illuminated AC Quiet Switch With Grounding Screw, 120/277 VAC, 15 A, 1/2 hp, 2 hpNon-stock product. Available to order - lead time may vary.
BrandDecora
MFG #5613-2I
Werner Part #1312502
UPC078477518243
Non-stock product. Available to order - lead time may vary.
BrandDecora
MFG #5613-2I
Werner Part #1312502
UPC078477518243
Product Description
Leviton® Decora® AC Quiet Switch, 3-Way Grounding Lighted Handle Illuminated, 120/277 VAC, 15 A, 1/2 hp, 2 hp, Rocker, Surface, Quick-Wire/Side Wired Terminal, Thermoplastic, Ivory, Environmental Conditions: -40 to 120 deg C Operating Temperature, 4.2 in H x 1.4 in W x 0.99 in D
Attributes
Documents
Features
Specifications
Attributes
Actuator TypeRocker
Amperage Rating15
ColorIvory
Country of OriginUnited States
Dimensions4.2 in H x 1.4 in W x 0.99 in D
Electrical Ratings1/2 hp, 2 hp
ManufacturerLeviton
MaterialThermoplastic
Mounting TypeSurface
Number of Poles1
Temperature Rating-40 to 120 deg C Operating Temperature
Terminal TypeQuick-Wire®/Side Wire
Type3-Way Grounding Lighted Handle Illuminated
Type / Style3-Way Grounding Lighted Handle Illuminated
Voltage Rating120/277 VAC
Documents
Features
Illuminated switch rocker illuminates when load is OFFSwitch border shields against dust and fits in wallplate to prevent rocker bindingSide wiring terminals accept both solid and stranded wire for easy installationFull rated current capacity with tungsten, fluorescent or resistive loadsMotor capacity is 80% of switch ratingConforms to NEMA and ANSI standardsPilot light switch rocker visible when load is ON, even in bright lightIlluminated switch does not require a neutralPilot light switch requires a neutral1/2 hp at 120 VAC, 2 hp at 277 VAC power rating
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL File No. E7458|CSA File No. LR3413|NOM 057|UL94 V-2 Flammability Rating
