Decora Plus 16362-HGW
Leviton® Decora® Plus 16362-HGW 1-Phase Duplex Extra Heavy Duty Self-Grounding Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Decora Plus 16362-HGW
Leviton® Decora® Plus 16362-HGW 1-Phase Duplex Extra Heavy Duty Self-Grounding Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, WhiteNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Leviton® Decora® Plus Straight Blade Receptacle, 1-Phase Duplex Extra Heavy Duty Self-Grounding, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA 5-20R, Commercial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Nylon, White, 46 in H x 1.52 in W x 1.14 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorWhite
Country of OriginMexico
Dimensions46 in H x 1.52 in W x 1.14 in D
GradeCommercial
Horsepower1 HP
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA 5-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
Type1-Phase Duplex Extra Heavy Duty Self-Grounding
Type / Style1-Phase Duplex Extra Heavy Duty Self-Grounding
Voltage Rating125 VAC
Documents
Features
Durable thermoplastic face in an array of contemporary colorsReceptacles have a locked-in mounting strap with a self-grounding clip riveted to the strapHospital grade tamper resistant receptacles include a unique shutter mechanism that opens easily for the insertion of 2 or 3-prong plugs while preventing entry by other small objects into either outlet slotHospital grade isolated ground receptacles protect sensitive electronic equipment and eliminate electromagnetic interference by providing a separate path to groundPower Indication™ meets UL 498 hospital grade identification requirements
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL 498HG File No. E13399|UL94 V-2 Flammability Rating
