Decora Plus 16362-GY
Leviton® Decora® Plus 16362-GY 1-Phase Duplex Heavy Duty Self-Grounding Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Gray
Decora Plus 16362-GY
Leviton® Decora® Plus 16362-GY 1-Phase Duplex Heavy Duty Self-Grounding Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, GrayBrandDecora Plus
MFG #16362-GY
Werner Part #1309329
UPC078477819470
BrandDecora Plus
MFG #16362-GY
Werner Part #1309329
UPC078477819470
Product Description
Leviton® Decora® Plus Straight Blade Receptacle, 1-Phase Duplex Heavy Duty Self-Grounding, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA 5-20R, Commercial Grade, -40 to 60 deg C, Back/Side Wired Terminal, Thermoplastic, Gray, 46 in H x 1.52 in W x 1.14 in D
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorGray
Country of OriginMX
Dimensions46 in H x 1.52 in W x 1.14 in D
GradeCommercial
Horsepower1 HP
ManufacturerLeviton
MaterialThermoplastic
NEMA RatingNEMA 5-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
Type1-Phase Duplex Heavy Duty Self-Grounding
Type / Style1-Phase Duplex Heavy Duty Self-Grounding
Voltage Rating125 VAC
Documents
Features
Shallow design for maximum wiring room in wallboxBack and side terminal wiring options for ease of installationHeavy gauge zinc plated steel locked-in wrap around strapHeavy duty triple wipe brass contacts for long service lifeExclusive V-shaped, serrated back wiring clamps for superior contact and conductivity
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL 498 File No. E13399|UL94 V-2 Flammability Rating
