Sta-Kon® RC10-10F
Thomas & Betts Sta-Kon® RC10-10F RC Series Insulated Fork Terminal, 12 to 10 AWG Conductor, 1 in L, Brazed Seam/Serrated Barrel, Copper, Yellow
Sta-Kon® RC10-10F
Thomas & Betts Sta-Kon® RC10-10F RC Series Insulated Fork Terminal, 12 to 10 AWG Conductor, 1 in L, Brazed Seam/Serrated Barrel, Copper, YellowIn Stock: 50More Info
|
In Stock: 50More Info
|
Product Description
Sta-Kon® Fork Terminal, Insulated, Series: RC Series, 12 to 10 AWG Conductor, #10 Stud, 1 in Length, Brazed Seam/Serrated Barrel, Fork Tongue, 0.37 in W x 0.04 in THK Tongue, 600 VAC, Specifications: 0.21 in Dia Maximum Insulation, 0.27 in Clearance, Nylon Insulation, 105 deg C, Copper, Electroplated Tin, Yellow
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam/Serrated
ColorYellow
Conductor size12 to 10 AWG
Country of OriginUS
FinishElectroplated Tin
ManufacturerThomas & Betts
MaterialCopper
SeriesRC Series
Temperature Rating105 deg C
Tongue Size0.37 in W x 0.04 in THK
Tongue TypeFork
TypeInsulated
Type / StyleInsulated
Voltage Rating600 VAC
Documents
Features
Nylon insulated with inner bronze insulation grip sleeve lengthens flex radius of conductor and eliminates conductor creepBrazed seam barrel is serrated for high pull-out valueNylon jacket is Color codedWT112M, WT145A, WT145C, WT2000, ERG4001, ERG4003 recommended tools
Specifications
0.21 in Dia Maximum Insulation, 0.27 in Clearance, Nylon Insulation
