nVent ILSCO PBTS-2-250
nVent ILSCO PBTS-2-250 Type PBTS 1-Sided Entry 2-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, Aluminum
nVent ILSCO PBTS-2-250
nVent ILSCO PBTS-2-250 Type PBTS 1-Sided Entry 2-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, AluminumIn Stock: 132More Info
|
BrandnVent ILSCO
MFG #PBTS-2-250
Werner Part #1333790
UPC783669079760
In Stock: 132More Info
|
BrandnVent ILSCO
MFG #PBTS-2-250
Werner Part #1333790
UPC783669079760
Product Description
nVent ILSCO NIMBUS® Multi-Tap Connector, Type PBTS 1-Sided Entry 2-Port Dual Rated Insulated, Aluminum/Copper Conductor, 600 VAC, 6 AWG to 250 kcmil Wire, 5/16 in Hex, 290 A, -45 to 90 deg C, Aluminum, 2.17 in L x 1.91 in W x 2.17 in H
Attributes
Documents
Features
Specifications
Attributes
Conductor TypeAluminum/Copper
Country of OriginMX
Dimensions2.17 in L x 1.91 in W x 2.17 in H
MaterialAluminum
Temperature Rating-45 to 90 deg C
TypeType PBTS 1-Sided Entry 2-Port Dual Rated Insulated
Type / StyleType PBTS 1-Sided Entry 2-Port Dual Rated Insulated
Voltage Rating600 VAC
Documents
Features
Broad wire range 14 AWG to 750 kcmilHigh dielectric strength plastisol is chemical resistantBlack cover is UV ratedRemovable port and screw plugsPre-filled with DE-OX® oxide inhibiting compoundPer NEC article 310-16 allowable ampacities are as follows 4 to 95 A, 1/0 to 170 A, 3/0 to 225 A, 250 to 290 A, 350 to 350 A, 600 to 475 A and 750 to 535 AFlexibility in the fieldEnsures reliabilityPatented screw designEntry port closurePrevents oxides from formingChemical resistantIncoming and outgoing conductors must be staggered
Specifications
6 AWG to 250 kcmil Wire, 5/16 in Hex, 290 A
